TWISTED PAIR (UTP) CAT6 (0.555) ALUMINIUM ARMOURED LAN CABLE

• Conductor Metal: Solid Bare Electrolytic Grade Copper
• Nominal Conductor Diameter: 0.555 +- 0.015
• Insulation: Polyethylene (HDPE)
• Pairing: Twisted Into Two Core
• No of Pair: 4 Pair Twisted Together
• Color Code: Grey
PAIR 1: ORANGE (White with orange)
PAIR 2: BROWN (White with brown)
PAIR 3: BLUE (White with blue)
PAIR 4: GREEN (White with green)
• INNER JACKET: PVC
• COLOUR OF INNER JACKET: D-Grey
• ALMOUR: Aluminum
• OUTER SHEATH: PVC
• COLOUR OF SHEATH: BLACK
• APPROXIMATE OD: 9.90+-0.30 mm
• SEQUENIAL MARKING: At Every Meter
• Cross Filler: HDPE
• PACKING: 305Mtrs In wooden Real

• LOW FREQUENCY ELECTRICAL PARAMETER
• Conductor Resistance (DC): 93.8 ohms/1000Mtr@20° Max
• Resistance Capacitance Unbalance: 5% Max
• Mutual Capacitance: 5.6 NF/100 Mtr Max
• Capacitance to 1KHZ 50+-NF/KM (Max)
• Capacitance Unbalance Pair/Ground

BULLET POINT

1- FIRE RETARDANT
2- SHIELDED CABLE & SPECIALLY FOR OUTDOOR
3- EASY TO TRANSPORT WOODEN REAL
4- BEST QUALITY LED COATING FOR ALL WEATHER CONDITIONS.
5- UL CERTIFIED
6- REGISTER ON GEM
7- ek Sle dk sbZ Hkh OUTDOOR CAT6 CABLE flQZ ,d BECOZ SECURITY MATTERS
8- lnhZ xeh Z ;k cjlkr CAT6 CABLE flQZ ,d BECOZ SECURITY MATTERS
